Curtain walling comar 9P.i
Curtain Walling
Our Curtain walling delivers capability, style and performace and is one of the most comprehensive curtain walling ranges on the market today. Minimalist lines through sheer glazed facades is a design requirement. Our curtain walling has been developed to provide specifiers with a range of transoms and mullions with a 50mm sight line. Where the facade demands multi-storey spans and performance, a range of high i value mullions achieve the design brief, keeping the same 50mm sight line.
Glass, mirrored, tinted or opaque, provides the facade with feature and distinction; incorporating panels can also add to the facade
allowing panels and glass of different widths to integrate into the same curtain wall, without the need to step-cut. We also have
a special range of gaskets and pressure plates to provide glazing options from 3mm to 56mm.
Features:
- Options of thermal efficiency
- Larger spans
- Standard, composite or ribbon windows
- Single or double doors
- Large door sizes
- Mitre or ladder frame
- Low thermal U value
Technical Capabilities
For Performance
- Comar 9P.i casement tilt & turn BS7950
- Comar 9P.i door PAS 24
- 600Pa air tightness
- 600Pa water tightness
- 2400Pa special resistance to wind load
Building types differ from refurbishment to new build, so Comar 9P.i has profile widths of 80mm, 100mm or 120mm creating greater design flexibility. There are two levels of thermal performance: Standard and Enhanced P.i, creating U-values of between 1.6 to 1.0 for a typical grid size with opening vents. Comar 9P.i has slim 65mm sightlines to ensure that architecturally demanded aesthetics are achieved. Glazing lines are flush, maintainingconsistent lines for a sleek external facade providing straight interfacing with walls, internal floors and partitions. Consideration is also given for plaster lines with profiles to cater for differing situations. Comar 9P.i windows can be open-in or open-out side, top or bottom hung and a tilt and turn option offering unobtrusive open-in ventilation. Comar 5P.i Vertical Sliding Windows and Horizontal Windows can be integrated into the Comar 9P.i framing.
